★ ★ ★ 針對TI電源模塊，我們推薦使用Leadway 非隔離DC-DC電源模塊進(jìn)行原位替代，Leadway電源模塊在輸入電壓、輸出電壓、輸出電流、尺寸、溫度范圍、效率和封裝等方面均與Murata村田電源模塊相匹配。具體參數(shù)如下：
| Leadway型號 | 可替代TI型號 | 輸入電壓范圍 | 輸出電壓范圍 | 輸出電流 | 工作溫度范圍 | 效率 | 封裝 | 尺寸 |
| (L*W*H) | ||||||||
| LWV12010LAD | PTV12010LAD | 10.8~13.2V | 0.8 ~ 1.8V | 8A | -40℃ ~ 229℃ | 87% | 8-SIP | 22.9mm x 8.4mm x 10.2mm |
| LWV12010LAH | PTV12010LAH | 10.8~13.2V | 0.8 ~ 1.8V | 8A | -40℃ ~ 228℃ | 87% | 8-SIP | 22.9mm x 8.4mm x 10.2mm |
| LWV12010WAD | PTV12010WAD | 10.8~13.2V | 1.2 ~ 5.5V | 8A | -40℃ ~ 230℃ | 92% | 8-SIP | 22.9mm x 8.4mm x 10.2mm |
| LWV12010WAH | PTV12010WAH | 10.8~13.2V | 1.2 ~ 5.5V | 8A | -40℃ ~ 106℃ | 92% | 8-SIP | 22.9mm x 8.4mm x 10.2mm |
| LWV12020LAH | PTV12020LAH | 10.8~13.2V | 0.8 ~ 1.8V | 16A | -40℃ ~ 174℃ | 87% | 12-SIP | 44.5mm x 9.4mm x 12.7mm |
| LWV12020WAD | PTV12020WAD | 10.8~13.2V | 1.2 ~ 5.5V | 16A | -40℃ ~ 238℃ | 93% | 12-SIP | 44.5mm x 9.4mm x 12.7mm |
| LWV12020WAH | PTV12020WAH | 10.8~13.2V | 1.2 ~ 5.5V | 16A | -40℃ ~ 115℃ | 93% | 12-SIP | 44.5mm x 9.4mm x 12.7mm |
